About This Product
  • Free UK mainland delivery included
  • Same-day dispatch when ordered before 2pm

Extra Wide Aluminium Loading Ramps

Designed to provide superior performance, these extra wide aluminium loading ramps are perfect for vehicles and lightweight machinery. With a core profile thickness of 100mm and a width of 400mm, these ramps offer a robust solution for loading needs.

  • Capacity of up to 1500kg, suitable for various applications.
  • Available with or without edges; default is without edges.
  • Four connection options available; default is rest on connection with a pin.
  • Custom load heights can be requested.
  • Not suitable for solid wheels on road surfacing machines.
  • Fully TÜV certified for peace of mind.

Product Specifications

Specification Details
Default Connection Rest On Connection
Capacity (kg) 1500
Height of Ramps Profile (mm) 100
Length (mm) 4000
Max Load Height (mm) 1200
Min. Load Height (mm) 1050
Weight per Ramp (kg) 27
Weight Per Pair (kg) 54
Width (mm) 400
Minimum Track Width (mm) 200
Maximum Track Width (mm) 320
Two Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 1250
Capacity Wheelbase 1250mm (kg) 1370
Capacity Wheelbase 1500mm (kg) 1500
Colour Option Black

FAQs

Q: Can these ramps be customised?
A: Yes, custom load heights are available upon request.

Q: Are these ramps suitable for solid wheels?
A: No, they are not suitable for solid wheels on road surfacing machines.

Q: What is the default connection type?
A: The default connection type is the rest on connection with a pin.
