Aluminium Loading Ramps – 5500mm x 510mm – 5070kg Capacity – Plant & Digger Use

Roll over image to zoom in Click on image to zoom

Aluminium Loading Ramps – 5500mm x 510mm – 5070kg Capacity – Plant & Digger Use

Name: Aluminium Loading Ramps – 5500mm x 510mm – 5070kg Capacity – Plant & Digger Use
Brand: Barriers Co
SKU: TRP-BC2707
Price: 6672.0 GBP
Availability: InStock

£6,672.00

Incl. VAT

In Stock & Ready to Ship

Free UK Shipping

In Stock — Order by 2pm for same-day dispatch

Free UK Delivery — arrives 1-3 days

UK & EU Safety Standards

Expert Support — 01282 270 214

14-Day Returns

🏗️ Ordering 10+ Units?

Get trade pricing on bulk orders. Request a Quote →

About This Product

Free UK mainland delivery included
Same-day dispatch when ordered before 2pm

Download Spec Sheet

PDF with image, specifications & dimensions

→

Chat With Us on WhatsApp

Added to Cart!

View Cart

- Payment
- Secure transaction
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
- Dispatches from
- UK warehouse

★★★★★

"Amazing quality and quick shipping!"

- Sarah K.

★★★★★

"Customer support was top-notch. Definitely recommend!"

- Jamal T.

★★★★☆

"Super smooth experience. Will shop again."

- Amanda R.

Overview

Discover our premium heavy-duty aluminium loading ramps, ideal for plant, digger, and tele-handler applications. With a capacity of up to 5070kg, these ramps are designed for robust and reliable performance.

Core profile thickness: 185mm
Available with or without edges (default is without)
Four connection options, default is rest on connection
Custom load heights available
Not suitable for solid wheels (use industrial ramps for steel tracks)
Fully TÜV certified
Quotes for bespoke ramps available

Product Specifications

Specification	Details
Default Connection	Rest On Connection
Capacity (kg)	5070
Height of Ramps Profile (mm)	185
Length (mm)	5500
Max Load Height (mm)	1650
Min. Load Height (mm)	1500
Weight per Ramp (kg)	86
Weight Per Pair (kg)	172
Width (mm)	510
Minimum Track Width (mm)	200
Maximum Track Width (mm)	430
Two Year Warranty	Yes
Connection Options Available	Yes
Customisable	Yes
Easy to Fit	Yes
European Made	Yes
Not Solid Wheels	Yes
Capacity Wheelbase 1000mm (kg)	3940
Capacity Wheelbase 1500mm (kg)	4430
Capacity Wheelbase 2000mm (kg)	5070
Colour Option	Black

FAQs

What is the maximum weight capacity of these ramps?

The ramps can support up to 5070kg, suitable for a variety of heavy-duty applications.

Are these ramps customisable?

Yes, custom load heights are available upon request.

What type of vehicles are these ramps suitable for?

These ramps are ideal for plant, digger, and tele-handler use. Not recommended for vehicles with solid wheels.

★★★★★
